The AIRMIXS W2000-03-G3/8" Air Filter Regulator is a compact, high-efficiency 2-in-1 air preparation unit engineered for mid-flow pneumatic machine circuits, control cabinets, and automated production systems. Utilizing G 3/8" female thread ports within a 2000-series body structure, this unit combines particle/moisture filtration and stable downstream pressure control into a single space-saving component, eliminating the need for separate filter and regulator bodies.
Built with a rugged die-cast aluminum housing and a clear polycarbonate bowl, it effectively extracts liquid water condensate, scale, and particulate rust to protect downstream valves, cylinders, and air tools. The top regulator knob features a push-to-lock detent mechanism—pull up to adjust operating pressure, then press down to lock the setting securely against operational vibration.
Feature / Specification | Detail |
|---|
Brand | AIRMIXS |
Model | W2000-03-G3/8" / W2000-03 |
Series / Size | 2000 Series (Compact) |
Component Type | Piggyback Air Filter Regulator (2-in-1 Unit) |
Port Size | G 3/8" (BSP) / NPT 3/8" |
Gauge Port Size | G 1/8" |
Filtration Rating | 5 µm (Standard) / 25 µm (Optional) |
Max Supply Pressure ($p_1$) | 1.0 MPa (10 Bar / 145 PSI) |
Proof Pressure | 1.5 MPa (15 Bar / 215 PSI) |
Adjustable Pressure Range ($p_2$) | 0.05 – 0.85 MPa (0.5 – 8.5 Bar / 7 – 123 PSI) |
Nominal Flow Rate | ~800 – 1,000 L/min |
Drain Mechanism | Manual Twist Drain / Semi-Auto Differential Drain |
Body Material | Heavy-Duty Die-Cast Aluminum Alloy |
Bowl Material | Polycarbonate (PC) |
Working Temperature Range | 5°C to 60°C (41°F to 140°F) |
Fluid Medium | Compressed Air / Inert Gases |
