The AIRMIXS PCF 12-03 is an industrial-grade, straight female push-to-connect fitting designed for connecting metric pneumatic tubing directly to a male threaded connection. As seen in AIRMIXS PCF 12-03.jpg, this component features a robust, full nickel-plated brass body coupled with a high-strength composite release collar, providing an exceptional leak-proof seal for 12mm outer diameter (OD) tubing.
Its straight, compact configuration makes it an ideal solution for tight spaces within pneumatic piping circuits, control valves, and air cylinders. Engineered for long-term reliability in automated production lines, packaging systems, and heavy-duty industrial machinery, it ensures maximum flow efficiency and effortless maintenance.
Key Features
One-Touch Connection: High-precision internal locking mechanism allows for instantaneous, tool-free tube insertion and instant air-tight sealing.
Full Metal Construction: Crafted with a premium nickel-plated brass body to offer high structural durability and corrosion resistance.
Internal Hexagonal Design: Features an ergonomic hexagonal body section allowing for secure, slip-free tightening with standard wrenches during installation.
Smooth Tubing Release: The rounded polymer collar enables quick, damage-free removal and reconfiguration of pneumatic lines.
Specification | Technical Data |
|---|
Model Number | PCF 12-03 |
Fitting Type | Straight Female Connector |
Port A (Tube Connection) | 12mm Tube OD |
Port B (Thread Connection) | 3/8" PT / BSPT / G (Female Thread) |
Body Material | Nickel-Plated Brass |
Release Collar Material | Industrial Polymer Composite (Grey) |
Applicable Tubing Material | Polyurethane (PU), Nylon (PA), Polyethylene (PE) |
Working Fluid | Compressed Air, Vacuum |
Operating Pressure Range | 0 to 150 PSI (0 to 1.0 MPa) |
Negative Pressure Range | -29.5 in Hg (-100 kPa) |
Operating Temperature Range | 32°F to 140°F / 0°C to 60°C |
