The MV-08 series provides a cost-effective and durable solution for precise airflow control. Its rotary-style actuator allows operators to switch the valve state and keep it in position, which is essential for tasks like maintaining a cylinder in its extended position during an assembly process.
Feature | Specification |
|---|
Model | MV-08 |
Valve Type | 5-Port, 2-Position (5/2 Way) |
Actuator Type | Rotary Twist Lever / Selector Switch |
Port Size (P, A, B) | 1/4" PT / G / BSPT |
Exhaust Port Size | 1/8" PT / BSPT |
Effective Area | 24 $mm^2$(Cv = 1.20) |
Operating Pressure | 0 – 0.8 MPa(0 – 114 PSI) |
Temperature Range | -5°C to 60°C(Up to 70°C for some models) |
Body Material | Aluminum Alloy (Anodized) |
