The AIRMIXS MR-MIDI-40N-1/2 is an industrial-grade pneumatic air filter regulator unit designed for accurate primary pressure regulation and reliable condensate/particle filtration. Built in a standard MIDI body size with $1/2"$ ports, this FRL series component removes water, rust, and pipe scale down to $40\text{ }\mu\text{m}$ , protecting air-operated machinery, pneumatic cylinders, and control systems from wear and contamination.
Parameter | Specification |
|---|
Brand | AIRMIXS |
Model / Part Number | MR-MIDI-40N-1/2 |
Port Size | 1/2" NPT / G-Thread |
Body Size | MIDI (55 mm Grid Dimension) |
Filter Rating | 40 µm |
Operating Pressure Range | 0.5 bar – 12 bar (7.25 psi – 174 psi) |
Max. Operating Pressure | 16 bar (232 psi) |
Temperature Range | -10°C to +60°C |
Drain Type | Manual / Semi-Automatic Drain |
Housing Material | Die-cast Zinc / Industrial Alloy |
Bowl Material | Polycarbonate with Protective Guard |
Compatible Media | Compressed Air, Neutral Industrial Gases |
