The AIRMIXS FRC-3/8 MINI is a complete 3-in-1 air preparation service combination unit (FRL) that integrates particulate filtration, pressure regulation, and mist lubrication into a compact assembly.Built in a MINI body size with 3/8" port connections, this unit filters out liquid condensate and dirt particles down to 40 µm, delivers constant downstream pressure through a locking regulation knob, and continuously injects fine oil mist to protect downstream pneumatic tools and actuators from friction and wear.
Parameter | Specification |
|---|
Brand | AIRMIXS |
Model / Part Number | FRC-3/8 MINI |
Port Size | 3/8" NPT / G-Thread |
Body Size | MINI (40 mm Grid Dimension) |
Unit Type | Integrated Filter-Regulator + Lubricator (FRL Combo) |
Filter Rating | 40 µm (Standard) |
Lubricator Type | Proportional Oil Mist |
Pressure Regulation Range | 0.5 bar – 12 bar (7.25 psi – 174 psi) |
Max. Operating Pressure | 16 bar (232 psi) |
Standard Nominal Flow Rate | 1,200 L/min |
Temperature Range | -10°C to +60°C |
Drain Type | Manual / Semi-Automatic Drain |
Actuator Lock | Rotary Knob with Detent |
Bowl Guard | Polycarbonate Bowls with Protective Metal Guards |
Recommended Lubricant Oil | ISO VG32 pneumatic tool oil |
Compatible Media | Compressed Air, Neutral Industrial Gases |
